Description
Technical Specifications
-
Speaker type: 2-way, bi-amped powered speaker, bass reflex
-
Frequency range (-10dB): 55 Hz – 20 kHz
-
dispersion (H x V): 90° x 90°
-
Crossover: 1.8 kHz: FIR-X Tuning™ (linear-phase FIR filter).
-
Maximum output level (measured peak, IEC noise @ 1m): 129 dB SPL
-
LF driver: 12″ cone, 2.5″ voice coil, ferrite magnet
-
HF driver: 1″ compression diaphragm, 1.4″ voice coil, ferrite magnet
-
Amplifier class: Class-D
-
Power handling: 1000 W (dynamic) / 465 W (continuous)
-
Cooling: fan cooling, 4 speeds
-
Power consumption: 74 W (1/8 power), 18 W (idle)
-
Power supply: 100 V, 100-120 V, 220-240 V, 50/60 Hz
-
A/D D/A converter: 24-bit 48 kHz sampling
-
Processors: HPF: OFF, 100 Hz, 120 Hz, 24 dB/oct; D-CONTOUR: FOH/MAIN, MONITOR, OFF.
-
Inputs: 2x XLR combo jack / 2x RCA (L/R)
-
Outputs: 1x XLR
-
Enclosure material: Plywood
-
Surface: Durable polyurea paint, black
-
Handle: 1x side
-
High stand flange: 1x 35 mm (Bottom)
-
Floor monitor angle: 57
-
Dimensions (W x D x H): 500 x 454 x 343 mm
-
Weight: 16.5 kg
