Description
-
Power consumption max. 220 W
-
Dimensions (W x D x H): 303 x 306 x 485 mm
-
Weight: 16.5 kg
Light source:
-
Light intensity: 52,400 Lux (1 m)
-
Radiation angle: 15°
-
White 100 W LED
Equipment features:
-
Dimmer: 0 – 100%
-
Stroboscope: 0-20 Hz
-
Pan: 540°, Tilt: 270°
-
Pan / Tilt resolution: 16-Bit
-
Colours: 8 Dichroic filters + white
-
Gobo wheel 1, rotating: 2 Glass + 5 metal gobos (interchangeable)
-
Gobo wheel 2: 8 Metal gobos
-
Focus: Engine
-
Iris: Motor
-
Rotating 3-facet prism
-
Colour display with gravity sensor
-
Connections: Three-pin and five-pin XLR input and output / Power Twist
Control:
-
Mode: DMX, Auto & Master / Slave
-
Control protocol: DMX512
-
Control variant: Advanced 19 Ch / Basic 15 Ch
